Choosing the correct Deutsch terminal or contact starts with the connector housing. First identify the connector family and contact size, then determine whether the housing requires a pin or socket contact and match the exact terminal to the wire used in the harness.
Contact size and wire gauge are separate specifications. A Size 16 contact, for example, does not automatically mean 16 AWG wire. Different terminals within the same nominal contact size can support different conductor ranges, constructions and plating options.
Deutsch Pin Contacts
Pin contacts form the male electrical contact side of a compatible connector pair. The housing part number and configuration determine whether pin contacts are required.
When selecting a pin terminal, confirm the contact size, wire range and connector-family compatibility rather than relying only on the terminal's appearance.
Deutsch Socket Contacts
Socket contacts form the complementary electrical contact side of the mating connector. As with pin terminals, the exact socket contact needs to match the housing contact size and the wire being terminated.
For commonly encountered contact-number families, 0460 is associated with pin contacts and 0462 with socket contacts. Always verify the complete terminal part number before ordering.
Deutsch Contact Sizes
Deutsch connector systems use several contact sizes across different families and configurations. This collection includes available contacts in Sizes 4, 8, 12, 16 and 20.
Common contact-size relationships across Deutsch connector families.Contact size Common family relationship Selection noteSize 20 Commonly associated with DTM Confirm exact housing and wire range.Size 16 Commonly associated with DT Available in multiple terminal and wire configurations.Size 12 Commonly associated with DTP and suitable heavy-duty configurations Confirm the exact connector family and contact specification.Size 8 Used in suitable heavy-duty connector configurations Verify housing compatibility before ordering.Size 4 Used in suitable larger-contact connector configurations Verify housing and wire requirements.
For more detail on contact-size terminology, see Deutsch Connector Sizes Explained.
Deutsch Contacts by Connector Family
Different connector families commonly use different contact systems. For example, DTM commonly uses Size 20 contacts, DT commonly uses Size 16 contacts and DTP commonly uses Size 12 contacts. Other families can use different or multiple contact sizes depending on the exact housing.
Use the connector part number and product specification to confirm compatibility rather than selecting a contact from the family name alone.
Solid and Other Contact Constructions
Deutsch terminals are available in different constructions and plating options. Where these attributes are provided in the product listing, use them together with the required contact size, pin/socket type and supported wire range to select the correct part.
Do not substitute one contact specification for another solely because both fit the same nominal contact size.
Complete the Connector Assembly
Once the correct contacts have been selected, confirm the matching connector housing, wedgelock and any required seals or accessories.
Browse Deutsch connector housings, wedgelocks, backshells and seals & accessories to complete the assembly.
For detailed contact-selection guidance, read the Deutsch Contacts, Terminals & Accessories Guide.
