DTV Series Connectors

Deutsch DTV Series connectors are sealed 18-way rectangular connectors designed for multi-circuit wiring where several connections need to be grouped into one compact housing. DTV commonly uses Size 16 contacts and provides a higher-position-count option within the wider Deutsch DT connector platform.

Use the filters below to narrow the range by connector style, contact type, keying and mounting configuration. Because DTV is centered on an 18-position format, the main selection differences are the housing side, contact configuration and exact keyed variant.

If you need fewer circuits, browse the DT Series. For other high-position-count connector options, explore the DRC and DRB Series. For technical background, see our DTV Series Connectors Explained guide.

Browse DRC/DRB/DTV Connector Family

View as

Choose the Right Deutsch DTV Connector

Choosing the right Deutsch DTV connector is mainly about matching the correct mating configuration. DTV is commonly used as an 18-way connector system, so confirm whether you need the plug or receptacle side, the required pin or socket configuration, keying and mounting arrangement.

DTV housings commonly use Size 16 contacts, but the exact contact and wire compatibility should still be checked against the individual housing and terminal specifications. Once the housing is selected, complete the assembly with compatible contacts and terminals, wedgelocks and any required seals and accessories.

DTV is particularly useful where a harness needs more circuits than common DT configurations without moving to a different high-density connector architecture. For detailed specifications, applications and selection checks, read DTV Series Connectors Explained.
