Deutsch | SKU:
DRC16-70SD-P013
DRC16-70SD-P013 - Seals and Accessories
HD34-24-35SN-059 forms part of the DEUTSCH DT range, engineered for secure sealed connections in tough conditions.
Designed for off highway equipment and industrial systems where sealing integrity and positive engagement are essential. Ideal for dependable OEM level repairs and new builds.
Quantity price breaks
1+
$42.25/each
DRC16-70SD-P013 - Seals and Accessories
Regular price
$42.25
Unit price
Unavailable
Product Specifications
| Cable exit angle | 180 ° |
| Connector keying code | D |
| Primary product color | Black |
| Blank cavity position | 0 |
| Connector modification | Bonded Front Seal |
| Number of positions | 70 |
| Number of rows | 5 |
| Contact current rating max | 13 A |
| Contact size | Size 16 |
| Contact type | Socket |
| Mating pin diameter | .063 in |
| Connector height | 1.421 in |
| Product length | 1.643 in |
| Product width | 4.094 in |
| Row to row spacing | .216 in |
| Nominal voltage architecture | 48 V |
| Operating voltage | 250 VDC |
| Centerline pitch | .216 in |
| Housing material | PPS GF |
| Compatible with agency standar | SAE J2030 |
| Ip rating | IP6K9K |
| Ul flammability rating | 20mm Flame Test per Standard UL-94 |
| Connector mounting type | Cable Mount (Free-Hanging) |
| Mating alignment | With |
| Mating alignment type | Keyed |
| Strain relief | Add By Accessory |
| Terminal position assurance | No |
| Circuit application | Power |
| Packaging method | Box |
| Packaging quantity | 50 |
| Connector contact terminates t | Wire & Cable |
| Connector housing type | Housing for Female Terminals |
| Connector shape | Rectangular |
| Connector system | Wire-to-Wire |
| Mixed hybrid connector | No |
| Primary locking feature | Integrated in Housing |
| Sealable | Yes |
| Operating temperature max | 257 °F |
| Operating temperature range | -67 – 257 °F |
| Connector position assurance c | No |
| Serviceable | Yes |
