Deutsch | SKU:
DTM04-12PB-L012
DTM04-12PB-L012 - DT Series
DRC16-70SB-P013 is a DEUTSCH DT connector built for reliable performance in demanding environments.
Used across heavy duty vehicles and exposed harness runs where durability matters. A straightforward solution when you need consistent performance without compromise.
Quantity price breaks
1+
$12.66/each
50+10% off
$11.39/each$12.66
100+19% off
$10.25/each$12.66
DTM04-12PB-L012 - DT Series
Regular price
$12.66
Unit price
Unavailable
Product Specifications
| Cable exit angle | 180 ° |
| Connector keying code | B |
| Primary product color | Black |
| Blank cavity position | 0 |
| Connector modification | Welded Flange |
| Number of positions | 12 |
| Number of rows | 2 |
| Contact current rating max | 7.5 A |
| Contact size | Size 20 |
| Contact type | Pin |
| Mating pin diameter | .04 in |
| Compatible insulation diameter | .053 – .12 in |
| Connector height | 1.72 in |
| Product length | 2.17 in |
| Product width | 1.4 in |
| Row to row spacing | .279 in |
| Nominal voltage architecture | 48 V |
| Operating voltage | 250 VDC |
| Centerline pitch | .165 in |
| Housing material | Nylon 66 GF |
| Compatible with agency standar | SAE J2030 |
| Ip rating | IP6K9K |
| Ul flammability rating | UL 94V-0 |
| Connector mounting type | Panel Mount |
| Mating alignment | With |
| Mating alignment type | Keyed |
| Strain relief | Without |
| Terminal position assurance | Yes |
| Circuit application | Power |
| Packaging method | Package |
| Packaging quantity | 1 |
| Connector contact terminates t | Wire & Cable |
| Connector housing type | Housing for Male Terminals |
| Connector shape | Rectangular |
| Connector system | Wire-to-Panel |
| Mixed hybrid connector | No |
| Primary locking feature | Integrated in Housing |
| Sealable | Yes |
| Operating temperature max | 257 °F |
| Operating temperature range | -67 – 257 °F |
| Connector position assurance c | No |
| Serviceable | Yes |
