Deutsch | SKU:
HD16-9-96S
HD16-9-96S - HD Series
HD34-24-23PE-059 forms part of the DEUTSCH DT range, engineered for secure sealed connections in tough conditions.
Designed for off highway equipment and industrial systems where sealing integrity and positive engagement are essential. Ideal for dependable OEM level repairs and new builds.
Quantity price breaks
1+
$7.95/each
50+10% off
$7.16/each$7.95
100+19% off
$6.44/each$7.95
HD16-9-96S - HD Series
Regular price
$7.95
Unit price
Unavailable
Product Specifications
| Cable exit angle | 180 ° |
| Primary product color | Gray |
| Blank cavity position | 0 |
| Connector modification | Threaded Rear |
| Number of positions | 9 |
| Contact current rating max | 13 A |
| Contact size | Size 16 |
| Contact type | Socket |
| Mating pin diameter | .063 in |
| Compatible insulation diameter | .1 – .15 in |
| Connector height | 1.63 in |
| Product length | 1.59 in |
| Product width | 1.59 in |
| Nominal voltage architecture | 24 V |
| Operating voltage | 250 VDC |
| Housing material | PA GF |
| Ip rating | IP6K9K |
| Ul flammability rating | 20mm Flame Test per Standard UL-94 |
| Connector mounting type | Cable Mount (Free-Hanging) |
| Mating alignment | With |
| Mating alignment type | Polarizing Rib |
| Strain relief | Without |
| Terminal position assurance | No |
| Circuit application | Power |
| Packaging method | Package |
| Packaging quantity | 1 |
| Connector contact terminates t | Wire & Cable |
| Connector housing type | Housing for Female Terminals |
| Connector shape | Circular |
| Connector system | Wire-to-Wire |
| Mixed hybrid connector | No |
| Primary locking feature | Integrated in Housing |
| Sealable | Yes |
| Operating temperature max | 257 °F |
| Operating temperature range | -67 – 257 °F |
| Connector position assurance c | No |
| Serviceable | Yes |
