Deutsch DT Series connectors are sealed rectangular electrical connectors used in vehicle, machinery and industrial wiring. This guide explains how the DT Series is structured, including DT04 receptacles, DT06 plugs, Size 16 contacts, position counts, mating configurations and common applications.
If you already know which housing you need, browse Deutsch DT Series Connectors.
The DT Series is often the first Deutsch connector family to compare when you need a sealed connector that is more robust than a compact signal connector but does not require the larger contacts commonly associated with DTP.
Below you will find the DT Series specifications, housing types, typical applications and guidance on compatible contacts, wedgelocks, seals and service tools.
Quick Answer: What Are DT Series Connectors?
DT Series connectors are sealed rectangular Deutsch connectors used for general-purpose wiring. They typically use Size 16 contacts and are commonly selected for lighting, relays, solenoids, equipment controls, automotive wiring and harness repairs.
| DT Series feature | What it means | Shop or guide |
|---|---|---|
| Connector family | Deutsch DT Series. | Explore DT Series Parts |
| Typical contact size | Size 16 contacts. | Browse Size 16 contacts |
| Typical use | General-purpose sealed wiring. | Selection guide |
| Common applications | Lighting, relays, solenoids, controls and equipment harnesses. | Application guide |
| Required components | Compatible contacts, wedgelocks and any required seals or accessories. | Browse DT assembly parts |
What Are DT Series Connectors?
DT Series connectors are part of the Deutsch rectangular connector range and are designed for serviceable sealed wiring connections. They are commonly used where a connector needs to be durable, disconnectable and suitable for demanding vehicle, machinery or equipment wiring.
In practical terms, DT connectors are often used as the general-purpose option between the smaller DTM Series and the larger-contact DTP Series.
Browse the DT connector housings if you already know this is the correct family for your application.
What Does DT Mean in a Deutsch Connector Part Number?
DT identifies the Deutsch DT connector family; it does not indicate wire gauge, contact size or the number of cavities. The rest of the part number identifies the housing configuration and other details.
For common standard housings, DT04 identifies the receptacle style and DT06 the plug style. The following number indicates the position count, while letters and modification suffixes help distinguish contact configuration, keying and special variants. For example, DT04-2P and DT06-2S form a common two-way pin-receptacle/socket-plug pairing; keyed 8-way and 12-way versions require closer matching.
For detailed suffix decoding, see How to Read Deutsch Connector Part Numbers. For the housing-side distinction, read DT04 vs DT06: Plug vs Receptacle Explained.
DT Series Specifications
DT Series specifications should be checked alongside the exact product listing, selected contacts and wire requirements. The connector housing, contacts, wedgelocks and installation method all affect the final assembly.
| Specification | DT Series detail | Selection note |
|---|---|---|
| Connector family | Deutsch DT Series | General-purpose sealed rectangular connector family. |
| Typical contact size | Size 16 | Confirm the exact contact and supported wire range before ordering. |
| Typical maximum contact rating | Up to 13 A for applicable Size 16 contacts. | Actual suitability depends on the exact contact, wire, circuit and operating conditions. |
| Common cavity counts | 2, 3, 4, 6, 8 and 12-way configurations. | Match cavity count to the number of circuits required. |
| Typical use | Lighting, relays, solenoids and general harness wiring. | Compare DTM for compact signal wiring and DTP for larger-contact power circuits. |
| Related components | Contacts, wedgelocks, seals, backshells and service tools. | Confirm whether the individual product is housing-only or includes additional components. |
For electrical-load guidance, read the Deutsch Connector Current Rating Guide.
If the terminology around Size 16, wire gauge or cavity count is unclear, see Deutsch Connector Sizes Explained.
Common DT Series Applications
Common applications for DT Series connectors include automotive wiring, work lights, auxiliary lighting, relays, solenoids, agricultural equipment, construction machinery, industrial controls and general wiring harness repairs.
| Application | Why DT Series may fit | Related guide |
|---|---|---|
| Automotive wiring | Useful for lighting, controls and general-purpose vehicle circuits. | Automotive wiring guide |
| Auxiliary lighting | Commonly used for 2-wire and multi-wire lighting connections. | Browse 2-way DT housings |
| Relays and solenoids | A useful starting point for many control and equipment circuits. | Application guide |
| Agricultural equipment | Suitable for many serviceable farm machinery wiring connections. | Agricultural equipment guide |
| Construction machinery | Useful for serviceable equipment wiring where environmental exposure needs to be considered. | Installation guide |
| Industrial equipment | Can suit general control, monitoring and equipment harness connections. | Selection guide |
DT vs DTM vs DTP
DT, DTM and DTP are related Deutsch rectangular connector families, but they use different contact systems and suit different wiring requirements. DT is generally the middle option between compact DTM and larger-contact DTP.
| Connector family | Typical contact size | General role | Consider when... | Shop |
|---|---|---|---|---|
| DTM Series | Size 20 | Compact signal wiring. | Space is limited or the circuit primarily carries signals. |
Browse DTM Series Connectors |
| DT Series | Size 16 | General-purpose sealed wiring. | You need a serviceable connector for many common control and equipment circuits. | Browse DT Series Connectors |
| DTP Series | Size 12 | Larger-contact power connections. | The circuit requires a larger contact system than standard DT. | Browse DTP Series Connectors |
For a deeper family comparison, read DT vs DTM vs DTP Connectors: What’s the Difference?.
How DT04 and DT06 Housing Types Work
DT connector housings are available in plug and receptacle configurations. In common DT part numbers, DT04 usually identifies a receptacle housing and DT06 usually identifies a plug housing.
| Receptacle housing | Mating plug housing | Cavity count | Shop |
|---|---|---|---|
| DT04-2P | DT06-2S | 2-way | Browse 2-way DT housings |
| DT04-3P | DT06-3S | 3-way | Browse 3-way DT housings |
| DT04-4P | DT06-4S | 4-way | Browse 4-way DT housings |
| DT04-6P | DT06-6S | 6-way | Browse 6-way DT housings |
| DT04-08PA (Key A) | DT06-08SA (Key A) | 8-way | Browse 8-way DT housings |
| DT04-12PA (Key A) | DT06-12SA (Key A) | 12-way | Browse 12-way DT housings |
The 8-way and 12-way rows show Key A examples. Keying, suffixes and special housing configurations can affect compatibility, so do not select mating halves from cavity count alone. For compatibility details, read the Deutsch Connector Mating Guide.
For a closer look at plug and receptacle terminology, see DT04 vs DT06: Plug vs Receptacle Explained.
DT Contacts and Terminals
DT Series connectors commonly use Size 16 contacts. The exact terminal must match the housing contact configuration, supported wire range and application.
| Contact Type | Common Part Number Prefix | Selection Note | Browse |
|---|---|---|---|
| Pin contact | 0460 | Used with compatible pin-contact housings such as DT04-P configurations. | See Size 16 pin example |
| Socket contact | 0462 | Used with compatible socket-contact housings such as DT06-S configurations. | See Size 16 socket example |
| Wire compatibility | Depends on exact terminal | Confirm the supported wire range of the specific contact part number. | Browse Size 16 contacts |
Contact size and wire gauge are not the same thing. Size 16 identifies the contact system; the exact terminal part number determines which wire range it supports.
Once the housing configuration and wire requirements are known, browse Deutsch Contacts & Terminals to compare available pin and socket contacts.
For a deeper component guide, read the Deutsch Contacts, Terminals & Accessories Guide.
DT Wedgelocks and Accessories
DT Series connectors use wedgelocks for secondary contact retention. The wedgelock must match the connector family, cavity count and pin- or socket-side configuration.
| Connector housing | Compatible wedgelock | Configuration | Shop |
|---|---|---|---|
| DT04-2P | W2P | 2-way pin-side DT receptacle | Shop W2P |
| DT06-2S | W2S | 2-way socket-side DT plug | Shop W2S |
For other cavity counts and configurations, browse Deutsch wedgelocks or use the Deutsch Wedgelock Guide.
You may also need seals and accessories, backshells or contact removal tools depending on the housing and installation.
How DT Series Connectors Are Used
DT Series connectors are a useful starting point when the application needs a serviceable sealed connector for general-purpose wiring. Compare another family when the physical size, signal requirements or electrical load point elsewhere.
| Application need | DT suitability | Selection note |
|---|---|---|
| Lighting circuits | Common use | Confirm circuit load, contact and wire requirements. |
| Relay and solenoid wiring | Common use | Confirm the electrical load and exact contact specification. |
| Agricultural equipment harnesses | Common use | Useful for many serviceable equipment connections. |
| Compact sensor wiring | Compare DTM | DTM may be preferable where connector size and signal wiring are the priority. |
| Higher-current power circuit | Compare DTP | Check whether the circuit requires the larger Size 12 contact system used by DTP. |
DT Assembly and Installation Notes
DT Series connectors should be assembled with compatible contacts, correctly terminated wire, fully seated contacts and the correct wedgelock. Installation should also account for harness routing, strain relief and access for future servicing.
| Check | Why it matters | Helpful guide |
|---|---|---|
| Correct contacts | The terminal must match the housing, contact size and wire. | Contacts guide |
| Correct crimp | The terminal and wire need to be prepared and crimped correctly before insertion. | Crimping guide |
| Contact seating | Contacts should be fully seated before the wedgelock is installed. | Not-locking guide |
| Wedgelock installation | The correct secondary lock helps retain the contacts in the housing. | Assembly guide |
| Harness routing | Routing should minimize unnecessary strain, abrasion and unsuitable heat exposure. | Installation guide |
DT Series Component Selection Checklist
Use this checklist before ordering DT Series connector components.
| Checklist item | Confirm before ordering | Shop or guide |
|---|---|---|
| Connector family | DT Series is appropriate for the application. | Browse DT Series Parts |
| Cavity count | The housing provides the required number of circuits. | Browse DT connector housings |
| Plug and receptacle | The mating halves have compatible configuration and keying. | Mating guide |
| Contacts | The Size 16 pin or socket terminal supports the wire being used. | Browse Size 16 contacts |
| Wedgelocks | The secondary lock matches the housing, cavity count and contact side. | Shop wedgelocks |
| Seals / accessories | Any required sealing or rear-of-connector accessories are identified. | Shop accessories |
| Service tools | Any required removal tool matches the relevant contact size and connector system. | Browse Size 16 service tools |
Common DT Series Selection Mistakes
Buying only the connector housing
A housing listing may not include the contacts, wedgelock or other components needed to complete the assembly. Check the product contents before ordering.
Confusing plug/receptacle with pin/socket
Housing style and contact gender describe different parts of the connector. A DT04 receptacle commonly uses pin contacts, while a DT06 plug commonly uses socket contacts.
Choosing a contact from contact size alone
DT commonly uses Size 16 contacts, but the exact contact must still match the pin/socket configuration and supported wire range.
Mixing DT, DTM and DTP components
These related families use different housings, contact systems and secondary locks. Do not assume components are interchangeable.
Choosing a connector family from current alone
Electrical load is only one part of connector selection. Contact size, wire requirements, cavity count, packaging and application also need to be considered.
Related DT Series Guides
Use these related guides to choose, assemble and service DT Series connectors.
- Shop Deutsch DT Series Connectors — browse DT plug and receptacle housings.
- DT vs DTM vs DTP Connectors — compare the three related rectangular families.
- Deutsch Connector Sizes Explained — understand contact size, wire gauge and cavity count.
- Complete Deutsch Connector Selection Guide — broader family selection guidance.
- Deutsch Connector Current Rating Guide — understand electrical-load considerations.
- Deutsch Connector Mating Guide — understand compatible plug and receptacle configurations.
- DT04 vs DT06: Plug vs Receptacle Explained — understand housing and contact terminology.
- DT04-2P Connector Guide — detailed guidance for a common 2-way DT receptacle.
- Deutsch Contacts, Terminals & Accessories Guide — choose compatible pin and socket contacts.
- Deutsch Wedgelock Guide — choose the correct secondary lock.
- How to Crimp Deutsch Connectors Correctly — contact and wire termination guidance.
- How to Assemble Deutsch DT Connectors — DT connector assembly guidance.
- How to Install Deutsch Connectors — installation and harness-routing guidance.
- Deutsch Connector Pin Removal Guide — remove installed contacts during servicing or repinning.
FAQs: DT Series Connectors Explained
What are DT Series connectors?
DT Series connectors are sealed rectangular Deutsch connectors commonly used for general-purpose vehicle, machinery and equipment wiring.
What are DT Series connectors used for?
Common applications include lighting, relays, solenoids, control circuits, automotive wiring, agricultural machinery, construction equipment and general wiring harnesses.
What contact size do DT Series connectors use?
DT Series connectors commonly use Size 16 contacts. The exact pin or socket terminal must still be matched to the housing and supported wire range.
Does a DT04 receptacle use pin or socket contacts?
Common DT04-P receptacle configurations use pin contacts, while common DT06-S plug configurations use socket contacts. The exact product suffix and housing specification should always be confirmed.
What do 0460 and 0462 mean for DT contacts?
Common Deutsch solid contacts beginning with 0460 are pin contacts, while 0462 identifies socket contacts. The full part number is required to determine the exact contact size, wire range and specification.
What is the difference between DT, DTM and DTP connectors?
DTM commonly uses smaller Size 20 contacts for compact signal wiring, DT commonly uses Size 16 contacts for general-purpose wiring, and DTP commonly uses larger Size 12 contacts for higher-current applications.
Are DT Series connectors waterproof?
DT Series connectors are designed as sealed connector systems, but the protection achieved by an installed assembly depends on using the correct compatible components and assembling them properly.
Do DT Series connectors need wedgelocks?
Compatible DT assemblies use wedgelocks for secondary contact retention. The wedgelock must match the housing, cavity count and pin- or socket-side configuration.
Final Recommendation
Choose DT Series connectors when you need a general-purpose sealed connector for applications such as lighting, controls, relays, solenoids, vehicle wiring or equipment harnesses.
Before ordering, confirm the cavity count, mating housing, keying, Size 16 contact requirement and exact wire-compatible terminal. Start with the DT plug and receptacle housings, then use the Contacts & Terminals collection filtered to Size 16 to select the correct pin or socket contacts.
Complete the assembly with the required wedgelocks, seals and accessories, backshells and contact removal tools.
