Comparison Guide
DT04 vs DT06 describes two common housing sides in the Deutsch DT Series connector housings. DT04 commonly identifies the receptacle housing, while DT06 commonly identifies the plug housing. For the common two-way configuration, DT04-2P mates with DT06-2S.
The important distinction is that plug vs receptacle describes the housing, while pin vs socket describes the contact configuration. DT04-2P is a receptacle with pin configuration; DT06-2S is a plug with socket configuration.
This guide explains DT04 vs DT06, the DT04-2P and DT06-2S mating pair, plug vs receptacle terminology, pin vs socket contacts, compatible wedgelocks, suffix variants and what to check before ordering.
Quick Recommendation
If you need the common two-way Deutsch DT mating pair, start with DT04-2P and DT06-2S. DT04-2P is the receptacle housing with pin configuration; DT06-2S is the mating plug housing with socket configuration.
Add the compatible W2P wedgelock for DT04-2P and W2S wedgelock for DT06-2S, then select the exact Size 16 pin and socket contacts that support the wire being used.
Remember: DT04 does not mean “pin” and DT06 does not mean “socket.” DT04 and DT06 identify housing patterns. The P and S in the full part number identify the pin or socket configuration.
What Is a Deutsch DT04 Connector?
A Deutsch DT04 connector is a receptacle housing in the Deutsch DT Series. DT04 describes a housing pattern, not a single part number or a specific number of positions. DT04 receptacles are available in different cavity counts and configurations, and they mate with appropriately matched DT06 plugs.
Choose the position count before selecting a particular DT04 housing: browse 2-way Deutsch connectors, 3-way Deutsch connectors, 4-way Deutsch connectors, 6-way Deutsch connectors or 12-way Deutsch connectors. These position-based collections can include more than one Deutsch connector series, so check that a selected product belongs to the DT Series connector-housing range.
When assembling or repairing a DT04 housing, check the complete part number before selecting contacts, wedgelocks and seals. Browse DT Series parts for the broader compatible component range.
DT04 vs DT06 at a Glance
The easiest way to understand DT04 vs DT06 is to separate the housing role from the contact configuration.
| Feature | DT04-2P | DT06-2S |
|---|---|---|
| Connector family | Deutsch DT Series | Deutsch DT Series |
| Housing type | Receptacle | Plug |
| Contact configuration | Pin | Socket |
| Part-number indicator | P = pin configuration | S = socket configuration |
| Positions | 2 | 2 |
| Common mating half | DT06-2S | DT04-2P |
| Compatible wedgelock | W2P | W2S |
| Common contact family | 0460 pin contacts | 0462 socket contacts |
DT04-2P vs DT06-2S: The Common 2-Way Mating Pair
DT04-2P and DT06-2S are not competing alternatives. They are opposite halves of a common two-way Deutsch DT connection.
| Feature | DT04-2P | DT06-2S |
|---|---|---|
| Connector family | Deutsch DT Series | Deutsch DT Series |
| Housing role | Receptacle | Plug |
| Positions | 2-way | 2-way |
| Contact configuration | Pin | Socket |
| Mating housing | DT06-2S | DT04-2P |
| Compatible wedgelock | W2P | W2S |
| Contact type required | Pin contacts | Socket contacts |
| Common contact number family | 0460 pin contacts | 0462 socket contacts |
| Browse | DT04-2P | DT06-2S |
The key point is simple: if your project uses a DT04-2P receptacle, the common mating configuration is DT06-2S. Confirm the complete part numbers, keying and any suffix-specific requirements when selecting exact variants.
How to Tell Whether You Have DT04 or DT06
The most reliable way to identify DT04 or DT06 is to check the full part number on the housing or product specification. Do not identify the connector only by looking at the electrical contacts.
Look for the housing prefix
For common DT Series configurations:
- DT04 commonly identifies the receptacle housing pattern.
- DT06 commonly identifies the plug housing pattern.
A full part number may look like DT04-2P or DT06-2S, with additional suffixes on some variants.
Check the number of positions
The number after the housing pattern identifies the position count in these common part numbers. For example:
- DT04-2P = 2 positions
- DT04-4P = 4 positions
- DT06-6S = 6 positions
Then check P or S
The final P or S in these common base part numbers describes the contact configuration:
- P = pin configuration
- S = socket configuration
This is separate from whether the housing is called a plug or receptacle.
Example: DT04-2P means a DT Series 04-pattern receptacle, two positions, with pin-contact configuration. DT06-2S means a DT Series 06-pattern plug, two positions, with socket-contact configuration.
If you need to identify the mating half from a complete part number, use the Deutsch Connector Mating Guide.
What Do You Need for a Complete DT04-2P and DT06-2S Connection?
The DT04-2P and DT06-2S housings are only part of the assembly. Before ordering, check the contacts, wedgelocks and wire requirements for both connector halves.
| Component | DT04-2P side | DT06-2S side |
|---|---|---|
| Housing | DT04-2P | DT06-2S |
| Contact type | Compatible Size 16 pin contacts | Compatible Size 16 socket contacts |
| Common contact family | 0460 pin contacts | 0462 socket contacts |
| Wedgelock | W2P | W2S |
| Wire | Match the exact selected contact's supported wire range. | Match the exact selected contact's supported wire range. |
| Crimp tooling | Use tooling specified for the exact contacts and wire being terminated. | |
| Removal / service tooling | Browse Deutsch contact removal tools for servicing or repinning installed contacts. | |
Do not assume every connector-housing listing includes contacts, wedgelocks or other accessories. Check the individual product listing before ordering.
For assembly guidance, see How to Assemble Deutsch DT Connectors.
DT04 vs DT06 Comparison Chart
DT04 and DT06 describe different housing roles within the same Deutsch DT connector system. They are not interchangeable, but compatible configurations are designed to mate together.
| Feature | DT04 | DT06 |
|---|---|---|
| Common housing role | Receptacle housing | Plug housing |
| Common example | DT04-2P | DT06-2S |
| Common contact configuration | P = pin configuration | S = socket configuration |
| Common 2-way mating pair | DT04-2P mates with DT06-2S | DT06-2S mates with DT04-2P |
| Connector family | DT Series | DT Series |
| Common contact size | Size 16 | Size 16 |
| Compatibility check | Confirm family, positions, configuration, keying and suffix. | Confirm family, positions, configuration, keying and suffix. |
DT04 vs DT06: Plug vs Receptacle Meaning
In the Deutsch DT Series, DT04 commonly identifies the receptacle housing and DT06 commonly identifies the plug housing.
The confusing part is that housing terminology and contact terminology are separate. A receptacle housing can contain pin contacts, while a plug housing can contain socket contacts.
For the common two-way mating pair:
| Term | What it describes | Example |
|---|---|---|
| Receptacle | Connector housing role | DT04-2P |
| Plug | Mating connector housing role | DT06-2S |
| Pin | Electrical contact configuration | P in DT04-2P |
| Socket | Electrical contact configuration | S in DT06-2S |
In other words, “receptacle” does not mean socket and “plug” does not mean pin. For DT04-2P and DT06-2S, the opposite is true: the receptacle has the pin configuration and the plug has the socket configuration.
P vs S: Pin vs Socket Contacts
The P and S characters in common DT part numbers identify the contact configuration. P indicates pin configuration and S indicates socket configuration.
| Code | Meaning | Example | Common contact family |
|---|---|---|---|
| P | Pin configuration | DT04-2P | 0460 pin contacts |
| S | Socket configuration | DT06-2S | 0462 socket contacts |
Contact part numbers vary by contact size, wire range and other configuration details. Confirm the exact contact listing rather than selecting a terminal from the 0460 or 0462 prefix alone.
Browse Deutsch Contacts & Terminals or read the Deutsch Contacts, Terminals & Accessories Guide for more help.
Common DT04 and DT06 Mating Pairs
DT04 receptacle housings and DT06 plug housings need compatible position counts and configurations. A two-way DT04 mates with a compatible two-way DT06; a four-way DT04 needs the corresponding compatible four-way DT06, and so on.
| DT04 receptacle housing | Mating DT06 plug housing | Positions | Browse |
|---|---|---|---|
| DT04-2P | DT06-2S | 2-way | DT04-2P / DT06-2S |
| DT04-3P | DT06-3S | 3-way | Browse 3-way Deutsch connectors |
| DT04-4P | DT06-4S | 4-way | Browse 4-way Deutsch connectors |
| DT04-6P | DT06-6S | 6-way | Browse 6-way Deutsch connectors |
| DT04-08PA | DT06-08SA | 8-way (Key A) | Browse DT Series Connectors |
| DT04-12PA | DT06-12SA | 12-way (Key A) | Browse 12-way Deutsch connectors |
These are common base mating configurations. Exact variants should still be checked for compatible keying and suffix requirements.
For compatibility beyond DT04 and DT06, use the Deutsch Connector Mating Guide.
What About DT04-2P and DT06-2S Suffix Variants?
You may see extended part numbers based on DT04-2P or DT06-2S. The base number identifies the core housing format, while an additional suffix can identify a particular product variant.
Do not assume every DT04-2P suffix variant mates with every DT06-2S suffix variant simply because the base numbers appear compatible. Check the complete product listings for keying, configuration and mating requirements.
Why keying matters
Keying or polarization can be used to prevent otherwise similar connector housings from mating. This is useful when several similar connectors are located near one another and must not be connected incorrectly.
That means matching:
- DT Series family
- DT04 and DT06 housing roles
- position count
- pin and socket configuration
still may not be enough if the exact keying or extended variant is different.
If you are decoding a longer part number, use How to Read Deutsch Connector Part Numbers.
DT04 Suffix Variant Examples
The DT04 prefix covers more than standard receptacle housings. Some suffixes identify changes to the seal system or integrated electrical components. These examples show why the full part number matters when comparing a DT04 connector with a DT06 mating half.
| Part number | What distinguishes it | What to verify |
|---|---|---|
| DT04-2P-RT02 | A 2-way DT04 receptacle with a molded-in diode, rather than an ordinary serviceable two-contact housing. | Check the integrated diode specification and mating requirements; do not assume the usual loose contacts or W2P wedgelock are required. |
| DT04-3P-CE02 | A 3-way black DT04 receptacle with an E-seal configuration. | Match a compatible 3-way DT06 plug and check wire-insulation diameter, contacts and the correct wedgelock. |
These parts are not interchangeable simply because both begin with DT04: the first has two positions and an integrated electrical component, while the second has three positions and a different sealing configuration. For detailed standard two-way specifications and assembly components, see the DT04-2P Connector Guide.
DT04 vs DT06 Buying Checklist
Use this checklist before ordering DT04, DT06 or DT04-2P / DT06-2S components.
| Check | What to confirm | Next step |
|---|---|---|
| Connector family | Both housings belong to the Deutsch DT Series. | Browse DT Series Connectors |
| Position count | Both halves use the compatible number of positions. | Check the complete part numbers. |
| Housing role | You have the required DT04 receptacle and compatible DT06 plug. | Check the Mating Guide |
| Contact configuration | Pin and socket configurations complement each other. | Browse contacts |
| Keying | The two exact variants use compatible keying or polarization. | Check both product specifications. |
| Wedgelocks | The wedgelock matches each housing and position count. | Browse wedgelocks |
| Suffix / variant | The complete part numbers are compatible with the intended mating pair. | Confirm each product listing. |
| Wire fit | The exact selected contacts support the wire being used. | Browse contacts |
Common DT04 vs DT06 Mistakes
Treating DT04-2P and DT06-2S as alternatives
They are opposite halves of the same common two-way connection. A complete mating pair normally uses both.
Thinking DT04 means pin and DT06 means socket
DT04 and DT06 describe housing patterns. The P and S portions of the complete part number identify the pin and socket configurations.
Confusing plug/receptacle with pin/socket
A receptacle does not automatically mean socket contacts, and a plug does not automatically mean pin contacts. In the common DT04-2P / DT06-2S pair, the DT04 receptacle has the pin configuration and the DT06 plug has the socket configuration.
Mixing position counts
A two-way DT04 cannot mate with a four-way DT06. Match the number of positions on both connector halves.
Ordering the wrong contacts
0460 is associated with pin contacts and 0462 with socket contacts, but the exact terminal must also support the required contact size and wire range.
Ignoring keying and suffix variants
A shared base number does not guarantee that every extended part-number variant is interchangeable. Confirm the complete product specifications before ordering.
Assuming the housing includes every assembly component
Contacts, wedgelocks and other components may need to be ordered separately. Check what is included on the exact product page.
Related Guides
- DT04-2P Connector Guide — specifications, compatibility and applications for the common two-way receptacle.
- Deutsch Connector Mating Guide — identify the mating connector using family, positions, contact configuration, keying and suffix.
- How to Read Deutsch Connector Part Numbers — understand family, housing, position and suffix information.
- DT Series Connectors Explained — understand the wider DT connector family.
- Deutsch Contacts, Terminals & Accessories Guide — choose compatible pin and socket contacts and related components.
- Deutsch Wedgelock Guide — identify compatible W2P, W2S and other secondary locks.
- How to Assemble Deutsch DT Connectors — wire and assemble the connector pair.
- Deutsch Connector Not Locking? — troubleshoot contact seating, wedgelocks and mating problems.
FAQs: DT04 vs DT06
What is the difference between DT04 and DT06?
DT04 commonly identifies the receptacle housing pattern in the Deutsch DT Series, while DT06 commonly identifies the plug housing pattern. The remainder of the part number identifies other characteristics such as position count and pin or socket configuration.
What is the difference between DT04-2P and DT06-2S?
DT04-2P is a two-way Deutsch DT receptacle housing with pin configuration, while DT06-2S is the common mating two-way plug housing with socket configuration.
Does DT04-2P mate with DT06-2S?
DT04-2P and DT06-2S form a common two-way DT mating configuration. Check any keying and suffix-specific requirements on the exact variants before ordering.
Is DT04 a plug or receptacle?
DT04 commonly identifies the receptacle housing in the Deutsch DT Series. DT04-2P is a common two-way example with pin-contact configuration.
Is DT06 a plug or receptacle?
DT06 commonly identifies the plug housing in the Deutsch DT Series. DT06-2S is a common two-way example with socket-contact configuration.
Does receptacle mean socket contact?
No. Receptacle describes the housing, while socket describes an electrical contact configuration. DT04-2P demonstrates the difference: it is a receptacle housing with pin-contact configuration.
Does plug mean pin contact?
No. Plug describes the housing. DT06-2S is a plug housing with socket-contact configuration.
What do P and S mean in DT04-2P and DT06-2S?
P identifies a pin-contact configuration and S identifies a socket-contact configuration. In the common two-way pair, DT04-2P uses pins and DT06-2S uses sockets.
Which wedgelocks fit DT04-2P and DT06-2S?
The common two-way DT04-2P receptacle uses the W2P wedgelock, while DT06-2S uses the W2S wedgelock.
What is the difference between 0460 and 0462 Deutsch contacts?
0460 part numbers are associated with pin contacts, while 0462 part numbers are associated with socket contacts. The exact contact must also match the required contact size, wire range and housing.
Are all DT04-2P and DT06-2S suffix variants interchangeable?
No. Additional suffixes can identify product-specific configurations or variants. Confirm the exact mating requirements, keying and complete product specifications rather than assuming compatibility from the base number alone.
Final Recommendation
Think of DT04 and DT06 as housing identifiers first. DT04 commonly identifies the receptacle side and DT06 commonly identifies the plug side. Then use the rest of the part number to confirm the position count and pin or socket configuration.
For the common two-way configuration, DT04-2P is the receptacle with pin configuration and DT06-2S is the mating plug with socket configuration. Complete the pair with compatible contacts and the correct W2P and W2S wedgelocks, while checking keying and any suffix-specific requirements on the exact housings.
Browse DT Series connectors, Contacts & Terminals and Wedgelocks to build the complete connector pair.
