DTM04-6P is the standard gray Deutsch DTM Series 6-way receptacle housing for Size 20 pin contacts, designed for sealed wire-to-wire electrical harness connections where a compact, serviceable multi-position interface is needed. This DEUTSCH DTM pin-contact receptacle uses Size 20 contacts and is intended to be paired with the corresponding DTM housing on the opposite contact side. The system is specified for up to 7.5 A per contact and 250 V AC/DC, with environmental protection dependent on correct terminals, cavity sealing and assembly. Choose this standard configuration when the special rear-cap, XCAP or colour variants are not required.
Typical applications include multi-circuit sensor and control harnesses, industrial equipment, off-highway machinery and automotive electrical systems needing several sealed signal connections in one housing.
-
Series: DEUTSCH DTM
-
Housing configuration: 6-way receptacle (pin-contact side)
-
Housing colour: Gray
-
Contact size: Size 20
-
Contact type: Pin
-
Sealing: Sealable; sealing performance depends on correctly specified components and assembly
-
Operating temperature: -55°C to +125°C
-
Operating voltage: 250 V AC/DC (TE housing specification)
-
Contact current rating (maximum): 7.5 A per contact; depends on contacts, wire and operating conditions
Dimensions
-
Connector height: 44.9 mm
-
Product length: 23.8 mm
-
Product width: 19.2 mm
-
Compatible insulation diameter: 1.35–3.05 mm
Mating Parts
The standard 6-way DTM plug family is DTM06-6S (socket-contact side). Confirm the precise mating housing version, keying, seal configuration and any cap or boot requirements for this DTM04-6P variant before purchase.
Compatible Parts
Select DEUTSCH DTM Size 20 pin contacts to suit the actual wire gauge and termination process, together with the appropriate secondary lock/wedgelock for the 6-way receptacle configuration. Check supplied assembly contents and part-specific TE accessory data rather than assuming every accessory is included or fits every modified housing.
